Over the past several decades, Si has been the representative electronic material in the field of semiconductor electronics. Nevertheless, our society has steadily become interested in the following topics of “energy harvesting”, “eco-friendly”, “low-power consumption”, etc. In this respect, quite many new materials have been proposed to date. Recently, “Materials Informatics” has accelerated the exploration of new materials. However, this background makes it difficult more and more to judge which material is better among a lot of candidates. Indeed, the most critical drawback is the difficulty in understanding of all the new materials in terms of “material science” as different materials possess different physical properties such as charge transport or doping mechanism and defects control; process also differs a lot according to materials. In this respect, “physical property analysis” plays a crucial role in understanding fundamentals. I have experienced a variety of skills of “physical property analysis”. Based on the “physical property analysis” skills, I have designed various new materials and developed the relevant electronic devices.
***Development of Next-Generation Electronics utilizing New Concepts and New Materials***
1. High-density Integration of Metal Oxide Electronics
High-density integration is essential in the field of electronics industry. However, for metal oxide electronics such as oxide thin-film transistors, the channel length is still several micrometers. Trade-off between contact resistance and hydrogen impurity induced channel shortening has been known to be responsible for the current drawback. In future research, I will clarify the role of hydrogen impurity in oxide semiconductors and design new oxide semiconductor that is robust to hydrogen impurities, which will be the route to the high-density integration of oxide electronics. It also realizes new electronics combining conventional Si electronics and oxide electronics.
2. Neuromorphic Devices
Artificial intelligence (AI) technologies attract much attention; machine learning techniques based on neural network algorithm have already been used to explore new materials. Accordingly, neuromorphic electronics are recently highly demanded. ReRAM and memristors have emerged as promising candidates for neuromorphic electronics; both exhibits resistive switching behavior. Mostly, metal oxides have been used for ReRAM in which oxygen vacancy defect (VO) plays a crucial role of resistive switching. However, it is still not clear whether VO based ReRAM is the best in terms of switching speed. Recently, I have already confirmed the validity of H- ion conduction in resistive switching. In future research, I will explore more various candidate materials for Neuromorphic Devices.

Over the past several decades, Si has been the representative electronic material in the field of semiconductor electronics. Nevertheless, our society has steadily become interested in the following topics of “energy harvesting”, “eco-friendly”, “low-power consumption”, etc. In this respect, quite many new materials have been proposed to date. Recently, “Materials Informatics” has accelerated the exploration of new materials. However, this background makes it difficult more and more to judge which material is better among a lot of candidates. Indeed, the most critical drawback is the difficulty in understanding of all the new materials in terms of “material science” as different materials possess different physical properties such as charge transport or doping mechanism and defects control; process also differs a lot according to materials. In this respect, “physical property analysis” plays a crucial role in understanding fundamentals. I have experienced a variety of skills of “physical property analysis”. Based on the “physical property analysis” skills, I have designed various new materials and developed the relevant electronic devices.
***Development of Next-Generation Electronics utilizing New Concepts and New Materials***
1. High-density Integration of Metal Oxide Electronics
High-density integration is essential in the field of electronics industry. However, for metal oxide electronics such as oxide thin-film transistors, the channel length is still several micrometers. Trade-off between contact resistance and hydrogen impurity induced channel shortening has been known to be responsible for the current drawback. In future research, I will clarify the role of hydrogen impurity in oxide semiconductors and design new oxide semiconductor that is robust to hydrogen impurities, which will be the route to the high-density integration of oxide electronics. It also realizes new electronics combining conventional Si electronics and oxide electronics.
2. Neuromorphic Devices
Artificial intelligence (AI) technologies attract much attention; machine learning techniques based on neural network algorithm have already been used to explore new materials. Accordingly, neuromorphic electronics are recently highly demanded. ReRAM and memristors have emerged as promising candidates for neuromorphic electronics; both exhibits resistive switching behavior. Mostly, metal oxides have been used for ReRAM in which oxygen vacancy defect (VO) plays a crucial role of resistive switching. However, it is still not clear whether VO based ReRAM is the best in terms of switching speed. Recently, I have already confirmed the validity of H- ion conduction in resistive switching. In future research, I will explore more various candidate materials for Neuromorphic Devices.
